Kualitas Lebar 400mm PCB Pita Tembaga Perekat Konduktif Murni pabrik

Lebar 400mm PCB Pita Tembaga Perekat Konduktif Murni

Nama Merek: OEM

Tempat Asal: CINA

Sertifikasi: ISO / SGS / RoHS

Jumlah pesanan minimum: 50kg

Harga: Bisa dinegosiasikan

Kemampuan pasokan: 550T Per Bulan

Waktu Pengiriman: 10 - 15 hari

Tanya Sekarang

Dapatkan Kutipan

Spesifikasi

Highlight Features

Pita Tembaga Perekat Konduktif 400mm

Pita Tembaga Perekat Konduktif 0.018mm

Pita Tembaga Perekat Konduktif 1.2mm

Aplikasi:

Elektronik

Lebar:

maks.400mm

Bahan:

Tembaga Merah

Nilai:

Tembaga murni

Cu (min):

99,90%

Paduan atau tidak:

Adalah paduan

Perlakuan:

Embossed

Ketebalan:

0,018mm~1,2mm

Fitur:

resistensi yang tinggi

Komentar:

berpemandu tunggal/berpemandu ganda

Penggunaan:

Isolasi

Deskripsi produk

Lebar 400mm PCB Pita Tembaga Perekat Murni Konduktif

Spesifikasi kertas foil tembaga :

1) Grade: c11000,C12200
2) Tembaga: cu min.99.90%
3) Ketebalan:0.018-1.2mm
4) Lebar: maks.400mm
5) Berat gulungan:6.5kg/mm
6) Komposisi Kimia: Cu >99.90% p:0.015%-0.040%
7) Temper: O, 1/4H, 1/2H, H O : HV100
8) Konduktivitas Listrik 20°C: C11000 >97% ,C12200 >80%

Informasi Grade dan Manufaktur:

Grade China	Merek Serupa Luar Negeri
	Internasional	USA	JEPANG	INGGRIS	JERMAN
	(ISO)	(ASTM)	(JIS)	(BS)	(DIN)
T2	Cu-ETP	C11000	C1100	C101	R-Cu57
TP2	Cu-DHP	C12200	C1220	C106	SI-CU

Grade	Negara China	Spesifikasi	Kekuatan Tarik	Perpanjangan	Kekerasan Vickers
T2	M	Ketebalan:0.005-1.2mm Lebar: (Maks)400mm Berat Gulungan:6.5kg/mm	>205	>30	-
T2	Y4		215-275	>25	55-100
TP2	Y2		245-345	>8	75-120

Fitur:

1) Viskositas yang baik, Tahan dingin
2) Ketahanan mekanis, Tahan kelembaban
3) Konduktivitas termal tinggi, Tahan minyak & asam
4) Tahan penuaan
5) Tahan api
6) Mudah disobek

Aplikasi:

1) Pegas listrik dan elektrik, sakelar
2) Bingkai timah
3) Konektor dan buluh osilasi
3) Bidang PCB
4) Kabel komunikasi
5) Pelindung kabel
6) Papan utama ponsel
7) Laminasi produksi baterai ion dengan film PI
8) Bahan pengumpul PCB (pendukung elektroda)

Lebar 400mm PCB Pita Tembaga Perekat Konduktif Murni 0
